| Dimensions | 11' Deep x 6' Wide x 86" High |
| Roll Size | 12" x 12" (304.8mm x 304.8mm) |
| Roll Bearings | Roller |
| Rolls | Internal Water Cooling |
| Screwdowns | Dual Handwheel with Motor Assist |
| Gearbox-Pinion Stand | DO James, Rated 100 HP, 12.36 to 1 Ratio |
| Spindles & Coupling | Universal |
| Drive Motor: | Reliance 100 HP, 500 Volts, 1150/2000 RPM, 103 AMPS, DC |
| Mill Stand Cross Section | 6-1/2" x 6-1/2" |
| Window Width | 12" |
| Equipped With | Turkshead Bracket Mounted on Left Side Purchaser to Supply New Electrical Controls |
