| Basic Wire Diameter | 3/16" (4.8mm) |
| Maximum Width Strip | 2" (51mm) |
| Standard Feed Length | 15" (381mm) |
| SPM | 32 - 130 |
| Front Slide Stroke | 1-3/4" (45mm) |
| Side Slide Stroke | 3-1/2" (89mm) |
| Rear Slide Stroke | 1-3/4" (45mm) |
| Stroke of Stripper | 2-7/32" (56mm) |
| Press Stroke | 1" (25mm) |
| Die Set Length | 16-1/4" (412mm) |
| Tonnage | 20 |
| Forming Bed Opening | 8-1/2" x 6-1/2" (216 x 165mm) |
| Motor HP | 3 HP |
| Electrics | AC Motor and Controls |
| Approx. Floor Size | 72" x 110" |
| Approx. Weight | 5,300 lbs |
| Equipped With | Wear Plates Tie Rolls Press Head Attachment 2 Plane Wire Straightener Shell Cams Electric Brake Reeves Variable Speed Drive |
