| Spindle Diameter | 1.58" |
| Thread/Form Diameter (In-Feed) | 1-1/2" (40mm) |
| Thread/Form Diameter (Thru-Feed) | 5/8" (16mm) |
| Thread/Form Length (In-feed) | Up to 3" (80mm) |
| Thread/Form Length (Thru-feed) | 20 Ft (6m) |
| Maximum Die Diameter | 4-3/4" (120mm) |
| Maximum Die Width | 3" (80mm) |
| Die I.D. | 1-1/2" (40mm) |
| Maximum Rolling Force | 7 Tons |
| Electrics | 460V |
| Approx. Floor Space | 32" x 34" |
| Approx. Weight | 2,200 lbs |
| Equipped With | With IAI 350MM Model 1X-NNN3515-5L-T1 Robotic Arm S/N: IA503744 |
